Fixtures

Various fixtures for different products.
Fixtures
All Products
Components Testing Fixture Material Testing Fixture Safety Testing Fixture Transformer Testing Fixture Cable Harness Testing Fixture Motor Coil Testing Fixture DC Bias Voltage Test Fixture
F420005 External Voltage Bias Fixture
F420005 External Voltage Bias Fixture

  • Terminal Connector：4-Terminal Pair, BNC
  • DUT Connection：4-Terminal
  • Dimensions (approx.)：145x102x46mm(W/H/D)
  • Weight (approx.)：396g
  • Applicable Models： 6632
  • Frequency：≤ 30 MHz
  • DC Bias Voltage/Current： ±40V / 100mA
  • Operating Temperature： 10° C to 40° C
Inquiry Compare
F5620 Transformer Scan Box
F5620 Transformer Scan Box

  • Applicable Models： 5265/5266/5267
  • Test Channel：20
  • Air pressure output： can be set to 7Kg
  • DUT Size：Fixture head can be customized
Inquiry Compare
F5648 Transformer Scan Box
F5648 Transformer Scan Box

  • Applicable Models： 5465/5466/5467
  • Test Channel：48
  • Air pressure output： can be set to 7Kg
  • DUT Size：Fixture head can be customized
Inquiry Compare
F7721 Single Scan Control Box
F7721 Single Scan Control Box

  • Applicable Models： 2-in-1 / 3-in-1 / ATP-5600
  • Test Channel：21
  • Air pressure output： can be set to 7Kg
  • DUT Size：Fixture head can be customized
Inquiry Compare
F7721D Dual Scan Control Box
F7721D Dual Scan Control Box

  • Applicable Models： 2-in-1 / 3-in-1 / ATP-5600
  • Test Channel：21
  • Air pressure output： can be set to 7Kg
  • DUT Size：Fixture head can be customized
Inquiry Compare
Transformer Fixture head
Transformer Fixture head

  • Application Models： Transformer Tester
Inquiry Compare
FX-000C26 Multiple DUT Testing Expand Box
FX-000C26 Multiple DUT Testing Expand Box

  • Applicable Models： 5265-5267/5465-5467
Inquiry Compare
7508 expansion box-8-channel
7508 expansion box-8-channel

  • Applicable Models： 7631

Inquiry Compare
7516 expansion box-16-channel
7516 expansion box-16-channel

  • Applicable Models： 7631
Inquiry Compare
